BMW 5 Series Sedan G30 Facelift 2020 Phytonic Blue rear view standing

THE 5

BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

The key facts and figures for the BMW 5 Series Sedan at a glance: engines, consumption, CO2 emissions and dimensions. Check out all the performance data such as displacement, horsepower, torque and acceleration – and find out which engine best meets your needs.

Read more
THE 5BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

TECHNICAL DATA.

Weight

Unladen weight EU in kg 1,970
Max. permissible weight in kg 2,560
Permitted load in kg 665
Permitted axle load front/rear in kg 1,170/1,455
Luggage capacity min. (seats up or roof down) in l 410
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,700
Trailer load 12% (braked) in kg 1,700

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 230
Acceleration 0–100 km/h in s 5.9
Electrical engine top speed in km/h -

Fuel consumption

Combined in l/100 km 1.7
CO2 combined emissions in g/km 39
Electricity consumption, combined in kWh/100km 16.4-15.9
Tank capacity, approx. in l 46

Wheels

Tyre dimensions front 225/55 R17 97 Y
Tyre dimensions rear 225/55 R17 97 Y
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km up to 57
Growth capacity of lithium-ion battery in kWh 12.0
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min 80 (109)/3,140
Electric Engine torque (Nm) at 1/min 265/100-2,500

Combined system power

Combined power kW (hp) 215 (292)
Combined torque Nm 420

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 530e Sedan:
Fuel consumption in l/100 km (combined): 1.8–1.6
CO2 emissions in g/km (combined): 40–36


The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.


Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2


The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.

Read more
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions.

  • BMW 530e Sedan:
    Fuel consumption in l/100 km (combined): 1.8–1.7
    CO2 emissions in g/km (combined): 42–39

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
