Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW X5.

Read more

TECHNICAL DATA OF THE BMW X5.

Select model

Weight

Unladen weight EU in kg 2,175-2,250
Max. permissible weight in kg 2,840-3,050
Permitted load in kg 875-740
Permitted axle load front/rear in kg 1,320-1,355/1,670-1,870
Luggage capacity min. (seats up or roof down) in l 650-550
Luggage capacity max. (seats down or roof up) in l 1,870-1,770
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 3,500-2,500
Trailer load 12% (braked) in kg 3,500-2,500

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94,6/82,0
Engine power in kW (hp) at 1/min 245 (333)/5,500-6,250
Engine torque (Nm) at 1/min 450/1,600-4,800
Compression ratio : 1 11.0

Performance

Top speed in km/h 243
Acceleration 0–100 km/h in s 5.9-5.7
Top speed electrical in km/h -

Fuel consumption

Combined in l/100 km 10.7-8.9
CO2 combined emissions in g/km 244-204
Electricity consumption combined in kWh/100km -
Tank capacity, approx. in l 83

Wheels

Tyre dimensions front 255/55 R18 109 W XL
Tyre dimensions rear 255/55 R18 109 W XL
Wheel dimensions and material front 8.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption, electricity consumption and CO2 emissions of the BMW X5.

BMW X5 xDrive40i:
Fuel consumption in l/100 km (combined): 10.7–8.9
CO2 emissions in g/km (combined): 244–204

BMW X5 xDrive45e:
Fuel consumption in l/100 km (combined): 1.7–1.2
CO2 emissions in g/km (combined): 40–27
Electricity consumption combined in kWh/100 km: 27.7–24.3

Official data on fuel consumption, CO2 emissions, power consumption and electric range were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp.

For more information on the official fuel consumption and official specific CO2 emissions of new passenger cars, see the ‘Guide to Fuel Consumption, CO2 Emissions, and Electricity Consumption of New Passenger Cars’, which is available free of charge at all sales outlets, from Deutsche AutomobilTreuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern- Scharnhausen, and at www.dat.de/co2
