BMW M135i xDRIVE: TECHNICAL DATA

THE 1BMW M135i xDRIVE: TECHNICAL DATA

TECHNICAL DATA OF THE BMW M135i xDRIVE.

Select model

Weight

Unladen weight EU in kg 1,600
Max. permissible weight in kg 2.085
Permitted load in kg 560
Permitted axle load front/rear in kg 1,120/1,020
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -
Trailer load (unbraked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 225 (306)/5,000-6,250
Engine torque (Nm) at 1/min 450/1,750-4,500
Compression ratio : 1 9.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.8

Fuel consumption

Combined in l/100 km 7.8
CO2–Emission, composite in 176
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/40 R18 92 Y XL
Tyre dimensions rear 225/40 R18 92 Y XL
Wheel dimensions and material front 8 J x 18 inches, light-alloy
Wheel dimensions and material rear 8 J x 18 inches, light-alloy

BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions of the BMW M135i xDrive.

  • BMW M135i xDrive:
    Fuel consumption in l/100 km (combined): 7.8
    CO2 emissions in g/km (combined): 176

    Images show optional equipment, screens and displays depend on equipment options.

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tyres available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
