THE iX1

THE BMW iX1: ENGINE & TECHNICAL DATA.

The most important facts and figures of the BMW iX1 at a glance:

Power consumption and electric range

Performance data such as kW/hp, torque and acceleration

Weight, dimensions, wheel and tyre sizes

Read more
THE iX1THE BMW iX1: ENGINE & TECHNICAL DATA.

TECHNICAL DATA OF THE BMW iX1.

Select model

Total Powertrain

Powertrain type Electric
Power in kW (hp) 230 (313) [7]
Torque in Nm 494
Transmission 1-speed, automatic
Drivetrain All-wheel drive

Electric motor

(Nominal) power/30 minutes power in kW (hp) 200 (272)/94 (128)
(Nominal) torque in Nm 494

Performance

Acceleration 0–100 km/h in s 5.6
Maximum speed in km/h 180

Fuel economy/emissions [1]

Energy consumption, combined WLTP in kWh/100 km 18.1-16.9
Electric range, WLTP in km [2] 417-439
Pass-by noise in dB(A) [3] - [8]

High-voltage/48 volt battery, charging [4]

Battery capacity in kWh 64.8
Maximum charging power AC/DC in kW 11/130
Charging time DC 10–80% in min 29
Added range after 10 minutes of high-power charging in km [5] 118-135
Charging time AC 0–100% in h 6.5

Dimensions/weights

Length/width/height in mm 4500/1845/1616
Wheelbase in mm 2692
Curb weight in kg [6] 2085
Luggage capacity in l 490-1495
Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1200/75

Total Powertrain

Powertrain type Electric
Power in kW (hp) 150 (204)
Torque in Nm 250
Transmission 1-speed, automatic
Drivetrain Front-wheel drive

Electric motor

(Nominal) power/30 minutes power in kW (hp) 150 (204)/68 (92)
(Nominal) torque in Nm 250

Performance

Acceleration 0–100 km/h in s 8.6
Maximum speed in km/h 170

Fuel economy/emissions [1]

Energy consumption, combined WLTP in kWh/100 km 17.2-15.4
Electric range, WLTP in km [2] 430-474
Pass-by noise in dB(A) [3] - [8]

High-voltage/48 volt battery, charging [4]

Battery capacity in kWh 64.8
Maximum charging power AC/DC in kW 11/130
Charging time DC 10–80% in min 29
Added range after 10 minutes of high-power charging in km [5] 132-152
Charging time AC 0–100% in h 6.5

Dimensions/weights

Length/width/height in mm 4500/1845/1616
Wheelbase in mm 2692
Curb weight in kg [6] 1940
Luggage capacity in l 490-1495
Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 750/75
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Power consumption and range.

  • BMW iX1 xDrive30*:
    Energy consumption, combined WLTP in kWh/100 km: 19.0–16.8
    Electric range, WLTP in km: 396–440

    Official figures for electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

    ** The performance depends on the state of charge of the battery.

Power consumption and range.

BMW iX1 xDrive30:
Energy consumption, combined WLTP in kWh/100 km: 18.1–17.0
Electric range, WLTP in km: 417–437



[1] Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists.. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195.



For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp


Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the "Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.


[2] Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.

[3] The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

[4] The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

[5] Temporary uprating <10 seconds in excess of specified nominal value
