BMW 2 Series Gran Tourer F46 2018 Estoril Blue metallic three-quarter front view driving on the road

THE 2

BMW 2 SERIES GRAN TOURER: ENGINES & TECHNICAL DATA

The most important facts and figures about the BMW 2 Series Gran Tourer at a glance: Find out here about engines, performance, weight, fuel consumption, CO2 emissions, dimensions, boot capacity and much more.

Read more
THE 2BMW 2 SERIES GRAN TOURER: ENGINES & TECHNICAL DATA

TECHNICAL DATA BMW 2 SERIES GRAN TOURER.

Weight
Unladen weight EU in kg
1,490
Max. permissible weight in kg
2,055
Permitted load in kg
640
Permitted axle load front/rear in kg
1,010/1,055
Luggage capacity min. (seats up or roof down) in l
560
Luggage capacity max. (seats down or roof up) in l
1,820
Trailer load (unbraked) in kg
745
Trailer load 8% (braked) in kg
1,100
Trailer load 12% (braked) in kg
1,100
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (HP) at 1/min
80 (109)/4,300-6,500
Engine torque (Nm) at 1/min
190/1,380-3,800
Compression ratio : 1
11.0
Performance
Top speed in km/h
188
Acceleration 0–100 km/h in s
11.7
Fuel consumption
Combined in l/100 km
6.5
CO2–Emission, composite in
148
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
205/60 R16 96W XL
Tyre dimensions rear
205/60 R16 96W XL
Wheel dimensions and material front
7 J x 16 inches, light-alloy
Wheel dimensions and material rear
7 J x 16 inches, light-alloy
Weight
Unladen weight EU in kg
1,490
Max. permissible weight in kg
2,055
Permitted load in kg
640
Permitted axle load front/rear in kg
1,010/1,055
Luggage capacity min. (seats up or roof down) in l
560
Luggage capacity max. (seats down or roof up) in l
1,820
Trailer load (unbraked) in kg
745
Trailer load 8% (braked) in kg
1,100
Trailer load 12% (braked) in kg
1,100
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (HP) at 1/min
80 (109)/4,300-6,500
Engine torque (Nm) at 1/min
190/1,380-3,800
Compression ratio : 1
11.0
Performance
Top speed in km/h
188
Acceleration 0–100 km/h in s
11.7
Fuel consumption
Combined in l/100 km
6.5
CO2–Emission, composite in
148
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
205/60 R16 96W XL
Tyre dimensions rear
205/60 R16 96W XL
Wheel dimensions and material front
7 J x 16 inches, light-alloy
Wheel dimensions and material rear
7 J x 16 inches, light-alloy
Weight
Unladen weight EU in kg
1,490
Max. permissible weight in kg
2,055
Permitted load in kg
640
Permitted axle load front/rear in kg
1,010/1,055
Luggage capacity min. (seats up or roof down) in l
560
Luggage capacity max. (seats down or roof up) in l
1,820
Trailer load (unbraked) in kg
745
Trailer load 8% (braked) in kg
1,100
Trailer load 12% (braked) in kg
1,100
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (HP) at 1/min
80 (109)/4,300-6,500
Engine torque (Nm) at 1/min
190/1,380-3,800
Compression ratio : 1
11.0
Performance
Top speed in km/h
188
Acceleration 0–100 km/h in s
11.7
Fuel consumption
Combined in l/100 km
6.5
CO2–Emission, composite in
148
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
205/60 R16 96W XL
Tyre dimensions rear
205/60 R16 96W XL
Wheel dimensions and material front
7 J x 16 inches, light-alloy
Wheel dimensions and material rear
7 J x 16 inches, light-alloy
Weight
Unladen weight EU in kg
1,490
Max. permissible weight in kg
2,055
Permitted load in kg
640
Permitted axle load front/rear in kg
1,010/1,055
Luggage capacity min. (seats up or roof down) in l
560
Luggage capacity max. (seats down or roof up) in l
1,820
Trailer load (unbraked) in kg
745
Trailer load 8% (braked) in kg
1,100
Trailer load 12% (braked) in kg
1,100
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (HP) at 1/min
80 (109)/4,300-6,500
Engine torque (Nm) at 1/min
190/1,380-3,800
Compression ratio : 1
11.0
Performance
Top speed in km/h
188
Acceleration 0–100 km/h in s
11.7
Fuel consumption
Combined in l/100 km
6.5
CO2–Emission, composite in
148
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
205/60 R16 96W XL
Tyre dimensions rear
205/60 R16 96W XL
Wheel dimensions and material front
7 J x 16 inches, light-alloy
Wheel dimensions and material rear
7 J x 16 inches, light-alloy
Weight
Unladen weight EU in kg
1,490
Max. permissible weight in kg
2,055
Permitted load in kg
640
Permitted axle load front/rear in kg
1,010/1,055
Luggage capacity min. (seats up or roof down) in l
560
Luggage capacity max. (seats down or roof up) in l
1,820
Trailer load (unbraked) in kg
745
Trailer load 8% (braked) in kg
1,100
Trailer load 12% (braked) in kg
1,100
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (HP) at 1/min
80 (109)/4,300-6,500
Engine torque (Nm) at 1/min
190/1,380-3,800
Compression ratio : 1
11.0
Performance
Top speed in km/h
188
Acceleration 0–100 km/h in s
11.7
Fuel consumption
Combined in l/100 km
6.5
CO2–Emission, composite in
148
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
205/60 R16 96W XL
Tyre dimensions rear
205/60 R16 96W XL
Wheel dimensions and material front
7 J x 16 inches, light-alloy
Wheel dimensions and material rear
7 J x 16 inches, light-alloy
Weight
Unladen weight EU in kg
1,490
Max. permissible weight in kg
2,055
Permitted load in kg
640
Permitted axle load front/rear in kg
1,010/1,055
Luggage capacity min. (seats up or roof down) in l
560
Luggage capacity max. (seats down or roof up) in l
1,820
Trailer load (unbraked) in kg
745
Trailer load 8% (braked) in kg
1,100
Trailer load 12% (braked) in kg
1,100
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (HP) at 1/min
80 (109)/4,300-6,500
Engine torque (Nm) at 1/min
190/1,380-3,800
Compression ratio : 1
11.0
Performance
Top speed in km/h
188
Acceleration 0–100 km/h in s
11.7
Fuel consumption
Combined in l/100 km
6.5
CO2–Emission, composite in
148
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
205/60 R16 96W XL
Tyre dimensions rear
205/60 R16 96W XL
Wheel dimensions and material front
7 J x 16 inches, light-alloy
Wheel dimensions and material rear
7 J x 16 inches, light-alloy
Weight
Unladen weight EU in kg
1,490
Max. permissible weight in kg
2,055
Permitted load in kg
640
Permitted axle load front/rear in kg
1,010/1,055
Luggage capacity min. (seats up or roof down) in l
560
Luggage capacity max. (seats down or roof up) in l
1,820
Trailer load (unbraked) in kg
745
Trailer load 8% (braked) in kg
1,100
Trailer load 12% (braked) in kg
1,100
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (HP) at 1/min
80 (109)/4,300-6,500
Engine torque (Nm) at 1/min
190/1,380-3,800
Compression ratio : 1
11.0
Performance
Top speed in km/h
188
Acceleration 0–100 km/h in s
11.7
Fuel consumption
Combined in l/100 km
6.5
CO2–Emission, composite in
148
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
205/60 R16 96W XL
Tyre dimensions rear
205/60 R16 96W XL
Wheel dimensions and material front
7 J x 16 inches, light-alloy
Wheel dimensions and material rear
7 J x 16 inches, light-alloy
Weight
Unladen weight EU in kg
1,490
Max. permissible weight in kg
2,055
Permitted load in kg
640
Permitted axle load front/rear in kg
1,010/1,055
Luggage capacity min. (seats up or roof down) in l
560
Luggage capacity max. (seats down or roof up) in l
1,820
Trailer load (unbraked) in kg
745
Trailer load 8% (braked) in kg
1,100
Trailer load 12% (braked) in kg
1,100
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (HP) at 1/min
80 (109)/4,300-6,500
Engine torque (Nm) at 1/min
190/1,380-3,800
Compression ratio : 1
11.0
Performance
Top speed in km/h
188
Acceleration 0–100 km/h in s
11.7
Fuel consumption
Combined in l/100 km
6.5
CO2–Emission, composite in
148
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
205/60 R16 96W XL
Tyre dimensions rear
205/60 R16 96W XL
Wheel dimensions and material front
7 J x 16 inches, light-alloy
Wheel dimensions and material rear
7 J x 16 inches, light-alloy

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 220d xDrive Gran Tourer:
Fuel consumption in l/100 km (combined): 4.9–4.8
CO2 emissions in g/km (combined): 128–126

The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
