BMW 2 Series Coupé, technical data

THE BMW 2 SERIES COUPÉ.

BMW 2 Series Coupé: technical data.

THE BMW 2 SERIES COUPÉ.BMW 2 Series Coupé: technical data.
    BMW 2 Series Coupé

    TECHNICAL DATA OF THE BMW 2 SERIES COUPÉ.

    Select model

    Weight

    Unladen weight EU in kg 1,420 [1,440]
    Max. permissible weight in kg 1,850 [1,870]
    Permitted load in kg 505 [505]
    Permitted axle load front/rear in kg 875/1,040 [900/1,040]
    Luggage capacity min. (seats up or roof down) in l 390 [390]
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 710 [720]
    Trailer load 8% (braked) in kg 1,500 [1,500]
    Trailer load 12% (braked) in kg 1,300 [1,300]

    Engine

    Cylinders/valves 3/4
    Capacity in ccm 1,499
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 100 (136)/4,400-6,000
    Engine torque (Nm) at 1/min 220/1,350-4,300
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 210 [210]
    Acceleration 0–100 km/h in s 8.8 [8.9]

    Fuel consumption

    Combined in l/100 km 7.2
    CO2–Emission, composite in 163
    Tank capacity, approx. in l 52

    Wheels

    Tyre dimensions front 205/55 R16 91 W
    Tyre dimensions rear 205/55 R16 91 W
    Wheel dimensions and material front 7 J x 16 inches, light-alloy
    Wheel dimensions and material rear 7 J x 16 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,480
    Max. permissible weight in kg 1,910
    Permitted load in kg 505
    Permitted axle load front/rear in kg 905/1,065
    Luggage capacity min. (seats up or roof down) in l 390
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 740
    Trailer load 8% (braked) in kg 1,500
    Trailer load 12% (braked) in kg 1,500

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
    Engine torque (Nm) at 1/min 270/1,350-4,600
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 230
    Acceleration 0–100 km/h in s 7.2

    Fuel consumption

    Combined in l/100 km 7.2
    CO2–Emission, composite in 165
    Tank capacity, approx. in l 52

    Wheels

    Tyre dimensions front 205/55 R16 91 W
    Tyre dimensions rear 205/55 R16 91 W
    Wheel dimensions and material front 7 J x 16 inches, light-alloy
    Wheel dimensions and material rear 7 J x 16 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,505
    Max. permissible weight in kg 1,935
    Permitted load in kg 505
    Permitted axle load front/rear in kg 915/1,085
    Luggage capacity min. (seats up or roof down) in l 390
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,500
    Trailer load 12% (braked) in kg 1,500

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 185 (252)/5,200-6,500
    Engine torque (Nm) at 1/min 350/1,450-4,800
    Compression ratio : 1 10.2

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 5.6

    Fuel consumption

    Combined in l/100 km 7.3
    CO2–Emission, composite in 166
    Tank capacity, approx. in l 52

    Wheels

    Tyre dimensions front 205/50 R17 89 Y
    Tyre dimensions rear 205/50 R17 89 Y
    Wheel dimensions and material front 7 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7 J x 17 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,565
    Max. permissible weight in kg 1,995
    Permitted load in kg 505
    Permitted axle load front/rear in kg 975/1,100
    Luggage capacity min. (seats up or roof down) in l 390
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg -
    Trailer load 8% (braked) in kg -
    Trailer load 12% (braked) in kg -

    Engine

    Cylinders/valves 6/4
    Capacity in ccm 2,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 250 (340)/5,500-6.500
    Engine torque (Nm) at 1/min 500/1,520-4,500
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 4.6

    Fuel consumption

    Combined in l/100 km 8.7
    CO2–Emission, composite in 197
    Tank capacity, approx. in l 52

    Wheels

    Tyre dimensions front 225/40 ZR18 88Y
    Tyre dimensions rear 245/35 ZR18 92Y XL
    Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
    Wheel dimensions and material rear 8 J x 18 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,615
    Max. permissible weight in kg 2,050
    Permitted load in kg 510
    Permitted axle load front/rear in kg 1,025/1,110
    Luggage capacity min. (seats up or roof down) in l 390
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg -
    Trailer load 8% (braked) in kg -
    Trailer load 12% (braked) in kg -

    Engine

    Cylinders/valves 6/4
    Capacity in ccm 2,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 250 (340)/5,500-6,500
    Engine torque (Nm) at 1/min 500/1,520-4,500
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 4.4

    Fuel consumption

    Combined in l/100 km 9.3
    CO2–Emission, composite in 210
    Tank capacity, approx. in l 52

    Wheels

    Tyre dimensions front 225/40 ZR18 88Y
    Tyre dimensions rear 245/35 ZR18 92Y XL
    Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
    Wheel dimensions and material rear 8 J x 18 inches, light-alloy

    FUEL CONSUMPTION AND CO2 EMISSIONS.

    BMW M240i Coupé:
    Fuel consumption in l/100 km (combined): 7.4–7.3
    CO2 emissions in g/km (combined): 168–167

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.

    Read more
    BMW wheels and tyres EU tyre label close-up

    BMW WHEELS & TYRES.

    We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.
    ​

    Fuel consumption and CO2 emissions.

    • BMW M240i Coupé:
      Fuel consumption in l/100 km (combined): 8.7
      CO2 emissions in g/km (combined): 197

      Diesel engines available until 09/2020

      The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

      Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

      The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
