THE BMW 2 SERIES ACTIVE TOURER: ENGINES & TECHNICAL DATA.

THE 2THE BMW 2 SERIES ACTIVE TOURER: ENGINES & TECHNICAL DATA.





The key facts and figures on the new BMW 2 Series Active Tourer at a glance: engines, fuel and power consumption, CO2 emissions, electric range and dimensions. Check out all the performance data such as displacement, horsepower, torque and acceleration – and find out which engine best meets your needs.

    TECHNICAL DATA OF THE BMW 2 SERIES ACTIVE TOURER.

    Total Powertrain [1][2]

    Powertrain type Petrol
    Power in kW (hp) 90 (122)
    Torque in Nm 230
    Transmission 7-speed, automatic
    Drivetrain Front-wheel drive

    TwinPower Turbo internal combustion engine [1]

    Cylinders 3
    Displacement in cm³ 1499
    Nominal power in kW (hp)/1/min 90 (122)/3900-6500
    Nominal torque in Nm/1/min 230/1500-3600

    Electric motor [2][3]

    (Nominal) power/30 minutes power in kW (hp) -
    (Nominal) torque in Nm -

    Performance

    Acceleration 0–100 km/h in s 10.3
    Maximum speed in km/h 206
    Electric top speed in km/h -

    Fuel economy/emissions [1][4]

    Fuel consumption, combined in l/100 km [5] 6.7-6.2
    CO2 emissions, combined WLTP in g/km [5] 152-140
    Energy consumption, combined WLTP in kWh/100 km [5] -
    Electric range, WLTP in km [6] -
    Stationary noise level in dB(A)/1/min [7] 72/3750
    Pass-by noise in dB(A) [7] 68

    High-voltage/48 volt battery, charging [8]

    Battery capacity in kWh -
    Maximum charging power AC/DC in kW -
    Charging time DC 10–80% in min -
    Charging time AC 0–100% in h -

    Dimensions/weights

    Length/width/height in mm 4386/1824/1576
    Wheelbase in mm 2670
    Curb weight in kg [9] 1545
    Luggage capacity in l 470-1455
    Fuel capacity in l 54
    Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1100/75

    Total Powertrain [1][2]

    Powertrain type Petrol
    Power in kW (hp) 100 (136)
    Torque in Nm 230
    Transmission 7-speed, automatic
    Drivetrain Front-wheel drive

    TwinPower Turbo internal combustion engine [1]

    Cylinders 3
    Displacement in cm³ 1499
    Nominal power in kW (hp)/1/min 100 (136)/4400-6500
    Nominal torque in Nm/1/min 230/1500-4000

    Electric motor [2][3]

    (Nominal) power/30 minutes power in kW (hp) -
    (Nominal) torque in Nm -

    Performance

    Acceleration 0–100 km/h in s 9.0
    Maximum speed in km/h 214
    Electric top speed in km/h -

    Fuel economy/emissions [1][4]

    Fuel consumption, combined in l/100 km [5] 6.7-6.2
    CO2 emissions, combined WLTP in g/km [5] 152-140
    Energy consumption, combined WLTP in kWh/100 km [5] -
    Electric range, WLTP in km [6] -
    Stationary noise level in dB(A)/1/min [7] 72/3750
    Pass-by noise in dB(A) [7] 68

    High-voltage/48 volt battery, charging [8]

    Battery capacity in kWh -
    Maximum charging power AC/DC in kW -
    Charging time DC 10–80% in min -
    Charging time AC 0–100% in h -

    Dimensions/weights

    Length/width/height in mm 4386/1824/1576
    Wheelbase in mm 2670
    Curb weight in kg [9] 1545
    Luggage capacity in l 470-1455
    Fuel capacity in l 54
    Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1300/75

    Total Powertrain [1][2]

    Powertrain type Petrol
    Power in kW (hp) 125 (170) [10]
    Torque in Nm 280 [10]
    Transmission 7-speed, automatic
    Drivetrain Front-wheel drive

    TwinPower Turbo internal combustion engine [1]

    Cylinders 3
    Displacement in cm³ 1499
    Nominal power in kW (hp)/1/min 115 (156)/4700-6500
    Nominal torque in Nm/1/min - ¹²/1500-4400

    Electric motor [2][3]

    (Nominal) power/30 minutes power in kW (hp) 14 (19)/10.5 (14)
    (Nominal) torque in Nm 55

    Performance

    Acceleration 0–100 km/h in s 8.1
    Maximum speed in km/h 221
    Electric top speed in km/h -

    Fuel economy/emissions [1][4]

    Fuel consumption, combined in l/100 km [5] 6.2-5.7
    CO2 emissions, combined WLTP in g/km [5] 144-131
    Energy consumption, combined WLTP in kWh/100 km [5] -
    Electric range, WLTP in km [6] -
    Stationary noise level in dB(A)/1/min [7] 72/3750
    Pass-by noise in dB(A) [7] 68

    High-voltage/48 volt battery, charging [8]

    Battery capacity in kWh 0.86
    Maximum charging power AC/DC in kW -
    Charging time DC 10–80% in min -
    Charging time AC 0–100% in h -

    Dimensions/weights

    Length/width/height in mm 4386/1824/1576
    Wheelbase in mm 2670
    Curb weight in kg [9] 1595
    Luggage capacity in l 415-1405
    Fuel capacity in l 54
    Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1300/75

    Total Powertrain [1][2]

    Powertrain type Petrol
    Power in kW (hp) 160 (218) [10]
    Torque in Nm 360 [10]
    Transmission 7-speed, automatic
    Drivetrain Front-wheel drive

    TwinPower Turbo internal combustion engine [1]

    Cylinders 4
    Displacement in cm³ 1998
    Nominal power in kW (hp)/1/min 150 (204)/5000-6500
    Nominal torque in Nm/1/min - ¹²/1500-4000

    Electric motor [2][3]

    (Nominal) power/30 minutes power in kW (hp) 14 (19)/10.5 (14)
    (Nominal) torque in Nm 55

    Performance

    Acceleration 0–100 km/h in s 7.0
    Maximum speed in km/h 241
    Electric top speed in km/h -

    Fuel economy/emissions [1][4]

    Fuel consumption, combined in l/100 km [5] 6.3-5.9
    CO2 emissions, combined WLTP in g/km [5] 146-134
    Energy consumption, combined WLTP in kWh/100 km [5] -
    Electric range, WLTP in km [6] -
    Stationary noise level in dB(A)/1/min [7] 73/3750
    Pass-by noise in dB(A) [7] 67

    High-voltage/48 volt battery, charging [8]

    Battery capacity in kWh 0.86
    Maximum charging power AC/DC in kW -
    Charging time DC 10–80% in min -
    Charging time AC 0–100% in h -

    Dimensions/weights

    Length/width/height in mm 4386/1824/1576
    Wheelbase in mm 2670
    Curb weight in kg [9] 1620
    Luggage capacity in l 415-1405
    Fuel capacity in l 54
    Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1500/75

    Total Powertrain [1][2]

    Powertrain type Petrol
    Power in kW (hp) 160 (218) [10]
    Torque in Nm 360 [10]
    Transmission 7-speed, automatic
    Drivetrain All-wheel drive

    TwinPower Turbo internal combustion engine [1]

    Cylinders 4
    Displacement in cm³ 1998
    Nominal power in kW (hp)/1/min 150 (204)/5000-6500
    Nominal torque in Nm/1/min - ¹²/1500-4000

    Electric motor [2][3]

    (Nominal) power/30 minutes power in kW (hp) 14 (19)/10.5 (14)
    (Nominal) torque in Nm 55

    Performance

    Acceleration 0–100 km/h in s 6.9
    Maximum speed in km/h 238
    Electric top speed in km/h -

    Fuel economy/emissions [1][4]

    Fuel consumption, combined in l/100 km [5] 6,9-6.4
    CO2 emissions, combined WLTP in g/km [5] 149-139
    Energy consumption, combined WLTP in kWh/100 km [5] -
    Electric range, WLTP in km [6] -
    Stationary noise level in dB(A)/1/min [7] 73/3750
    Pass-by noise in dB(A) [7] 67

    High-voltage/48 volt battery, charging [8]

    Battery capacity in kWh 0.86
    Maximum charging power AC/DC in kW -
    Charging time DC 10–80% in min -
    Charging time AC 0–100% in h -

    Dimensions/weights

    Length/width/height in mm 4386/1824/1576
    Wheelbase in mm 2670
    Curb weight in kg [9] 1690
    Luggage capacity in l 415-1405
    Fuel capacity in l 54
    Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1500/75

    Total Powertrain [1][2]

    Powertrain type Diesel
    Power in kW (hp) 110 (156)
    Torque in Nm 360
    Transmission 7-speed, automatic
    Drivetrain Front-wheel drive

    TwinPower Turbo internal combustion engine [1]

    Cylinders 4
    Displacement in cm³ 1995
    Nominal power in kW (hp)/1/min 110 (156)/3750-4000
    Nominal torque in Nm/1/min 360/1500-2500

    Electric motor [2][3]

    (Nominal) power/30 minutes power in kW (hp) -
    (Nominal) torque in Nm -

    Performance

    Acceleration 0–100 km/h in s 8.8
    Maximum speed in km/h 220
    Electric top speed in km/h -

    Fuel economy/emissions [1][4]

    Fuel consumption, combined in l/100 km [5] 5.2-4.8
    CO2 emissions, combined WLTP in g/km [5] 136-125
    Energy consumption, combined WLTP in kWh/100 km [5] -
    Electric range, WLTP in km [6] -
    Stationary noise level in dB(A)/1/min [7] 76/3000
    Pass-by noise in dB(A) [7] 68

    High-voltage/48 volt battery, charging [8]

    Battery capacity in kWh -
    Maximum charging power AC/DC in kW -
    Charging time DC 10–80% in min -
    Charging time AC 0–100% in h -

    Dimensions/weights

    Length/width/height in mm 4386/1824/1576
    Wheelbase in mm 2670
    Curb weight in kg [9] 1620
    Luggage capacity in l 470-1455
    Fuel capacity in l 54
    Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1400/75

    Total Powertrain [1][2]

    Powertrain type Diesel
    Power in kW (hp) 155 (211) [10]
    Torque in Nm 400
    Transmission 7-speed, automatic
    Drivetrain All-wheel drive

    TwinPower Turbo internal combustion engine [1]

    Cylinders 4
    Displacement in cm³ 1995
    Nominal power in kW (hp)/1/min 145 (197)/4000
    Nominal torque in Nm/1/min 400/1500-2750

    Electric motor [2][3]

    (Nominal) power/30 minutes power in kW (hp) 14 (19)/10.5 (14)
    (Nominal) torque in Nm 55

    Performance

    Acceleration 0–100 km/h in s 7.3
    Maximum speed in km/h 233
    Electric top speed in km/h -

    Fuel economy/emissions [1][4]

    Fuel consumption, combined in l/100 km [5] 5.0-4.6
    CO2 emissions, combined WLTP in g/km [5] 132-123
    Energy consumption, combined WLTP in kWh/100 km [5] -
    Electric range, WLTP in km [6] -
    Stationary noise level in dB(A)/1/min [7] 75/3000
    Pass-by noise in dB(A) [7] 67

    High-voltage/48 volt battery, charging [8]

    Battery capacity in kWh 0,86
    Maximum charging power AC/DC in kW -
    Charging time DC 10–80% in min -
    Charging time AC 0–100% in h -

    Dimensions/weights

    Length/width/height in mm 4386/1824/1576
    Wheelbase in mm 2670
    Curb weight in kg [9] 1730
    Luggage capacity in l 415-1405
    Fuel capacity in l 54
    Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1500/75

    Total Powertrain [1][2]

    Powertrain type Petrol - plug-in hybrid
    Power in kW (hp) 180 (245) [11]
    Torque in Nm 477 [11]
    Transmission 7-speed, automatic
    Drivetrain All-wheel drive

    TwinPower Turbo internal combustion engine [1]

    Cylinders 3
    Displacement in cm³ 1499
    Nominal power in kW (hp)/1/min 100 (136)/4400-6500
    Nominal torque in Nm/1/min - ¹²/1500-4400

    Electric motor [2][3]

    (Nominal) power/30 minutes power in kW (hp) 80 (109)/60 (- [10])
    (Nominal) torque in Nm 247

    Performance

    Acceleration 0–100 km/h in s 6.7
    Maximum speed in km/h 195
    Electric top speed in km/h 140

    Fuel economy/emissions [1][4]

    Fuel consumption, combined in l/100 km [5] 0.8-0.6
    CO2 emissions, combined WLTP in g/km [5] 21-19
    Energy consumption, combined WLTP in kWh/100 km [5] 18.1-16.2
    Electric range, WLTP in km [6] 78-88
    Stationary noise level in dB(A)/1/min [7] 73/3750
    Pass-by noise in dB(A) [7] 68

    High-voltage/48 volt battery, charging [8]

    Battery capacity in kWh 14.2
    Maximum charging power AC/DC in kW 11
    Charging time DC 10–80% in min -
    Charging time AC 0–100% in h 1:45

    Dimensions/weights

    Length/width/height in mm 4386/1824/1570
    Wheelbase in mm 2670
    Curb weight in kg [9] 1900
    Luggage capacity in l 406-1370
    Fuel capacity in l 47
    Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1400/75

    Total Powertrain [1][2]

    Powertrain type Petrol - plug-in hybrid
    Power in kW (hp) 240 (326) [11]
    Torque in Nm 477 [11]
    Transmission 7-speed, automatic
    Drivetrain All-wheel drive

    TwinPower Turbo internal combustion engine [1]

    Cylinders 3
    Displacement in cm³ 1499
    Nominal power in kW (hp)/1/min 110 (150)/4700-6500
    Nominal torque in Nm/1/min - ¹²/1500-4400

    Electric motor [2][3]

    (Nominal) power/30 minutes power in kW (hp) 130 (177)/60 (- [10])
    (Nominal) torque in Nm 247

    Performance

    Acceleration 0–100 km/h in s 5.5
    Maximum speed in km/h 205
    Electric top speed in km/h 140

    Fuel economy/emissions [1][4]

    Fuel consumption, combined in l/100 km [5] 1.1-0.9
    CO2 emissions, combined WLTP in g/km [5] 25-20
    Energy consumption, combined WLTP in kWh/100 km [5] 17.9-16.0
    Electric range, WLTP in km [6] 76-87
    Stationary noise level in dB(A)/1/min [7] 70/3750
    Pass-by noise in dB(A) [7] 66

    High-voltage/48 volt battery, charging [8]

    Battery capacity in kWh 14.2
    Maximum charging power AC/DC in kW 11
    Charging time DC 10–80% in min -
    Charging time AC 0–100% in h 1:45

    Dimensions/weights

    Length/width/height in mm 4386/1824/1570
    Wheelbase in mm 2670
    Curb weight in kg [9] 1920
    Luggage capacity in l 406-1370
    Fuel capacity in l 47
    Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg 1400/75
    BMW wheels and tyres EU tyre label close-up

    BMW WHEELS & TYRES.

    We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

    Fuel consumption, power consumption and CO2 emissions of the BMW 2 Series Active Tourer.


    BMW 223i Active Tourer:
    Fuel consumption, combined WLTP in l/100 km: 6.3–5.9
    CO2 emissions, combined WLTP in g/km: 144–133



    BMW 225e xDrive Active Tourer:
    Fuel consumption, combined WLTP in l/100 km: 0.9–0.8
    CO2 emissions, combined WLTP in g/km: 21–19
    Energy consumption, combined WLTP in kWh/100 km: 18.1–16.1
    Electric range, WLTP in km: 78–88



    BMW 230e xDrive Active Tourer:
    Fuel consumption, combined WLTP in l/100 km: 0.9–0.8
    CO2 emissions, combined WLTP in g/km: 21–19
    Energy consumption, combined WLTP in kWh/100 km: 17.9–16.1
    Electric range, WLTP in km: 78–88



    BMW 225e xDrive and BMW 230e xDrive Active Tourer are expected to be available from 7/2022.

    The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission.

    [1]
    Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

    [2]
    For plug-in hybrid: Electric drive depending on battery charging level.

    [3]
    For plug-in hybrid: At temperatures below freezing, the fully electric drive system is only available after a few kilometres of driving, once the battery has heated to operational temperature.

    [4]
    Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195.



    For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp



    Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the "Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.


    [5]
    For plug-in hybrid: Weighted, combined (EC AC Charge Weighted)

    [6]
    Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.



    [7] The values measured in accordance with UN/ECE Regulation No. 51/EU Regulation 540/2014 are rounded.



    [8] The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

    [9]
    The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.



    [10] Provisional figures; any missing figures were unavailable at the time of publication.



    [11] Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value).



    [12] Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value). Electric drive depending on battery charging level.

    Read more

    Fuel consumption, power consumption and CO2 emissions of the BMW 2 Series Active Tourer.

    • Disclaimer reference invalid
