BMW Z4 G29 2022 Thundernight technical data

THE Z4

BMW Z4 ROADSTER: ENGINES & TECHNICAL DATA.

THE Z4BMW Z4 ROADSTER: ENGINES & TECHNICAL DATA.
BMW Z4: Overview

The key facts and figures for the BMW Z4 Roadster at a glance:


  • Engine, consumption and CO2 emissions
  • Performance data such as displacement, hp, Nm and acceleration
  • Weight, dimensions, wheel and tyre sizes
Read more

BMW Z4 ROADSTER: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1,495 [1,505]
Max. permissible weight in kg 1,725 [1,740]
Permitted load in kg 305 [310]
Permitted axle load front/rear in kg 830/935 [830/935]
Luggage capacity in l 281 [281]
Trailer load (unbraked) in kg -
Trailer load 12% (braked) in kg -
Trailer load 8% (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 120-145 (163-197)/4,000-6,500 - 4,500-6,500
Engine torque (Nm) at 1/min 320/1.450-3,500 - 1,450-4,200
Compression ratio : 1 10.2

Performance

Top speed in km/h 241-227 [240-226]
Acceleration 0–100 km/h in s 7.6-6.8 [7.4-6.6]

Fuel consumption

Combined in l/100 km 7.2-6.8 [7.2-6.8]
CO2 combined emissions in g/km 165-156 [164-155]
Tank capacity, approx. in l 52

Wheels

Tyre dimensions front 225/50 R17 94 W
Tyre dimensions rear 255/45 R17 98 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1.505
Max. permissible weight in kg 1,740
Permitted load in kg 310
Permitted axle load front/rear in kg 830/935
Luggage capacity in l 281
Trailer load (unbraked) in kg -
Trailer load 12% (braked) in kg -
Trailer load 8% (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 190 (258)/5,000-6,500
Engine torque (Nm) at 1/min 400/1,550-4,400
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.4

Fuel consumption

Combined in l/100 km 7.3-6.9
CO2 combined emissions in g/km 166-157
Tank capacity, approx. in l 52

Wheels

Tyre dimensions front 225/50 R17 94 W
Tyre dimensions rear 255/45 R17 98 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,555
Max. permissible weight in kg 1,860
Permitted load in kg 305
Permitted axle load front/rear in kg 865/995
Luggage capacity in l 281
Trailer load (unbraked) in kg -
Trailer load 12% (braked) in kg -
Trailer load 8% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 250 (340)/5,000-6,500
Engine torque (Nm) at 1/min 500/1,600-4,500
Compression ratio : 1 11.0

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.5

Fuel consumption

Combined in l/100 km 8.0-7.8
CO2 combined emissions in g/km 182-177
Tank capacity, approx. in l 52

Wheels

Tyre dimensions front 255/40 ZR18 95 Y
Tyre dimensions rear 275/40 ZR18 99 Y
Wheel dimensions and material front 9 J x 18 inches, light-alloy
Wheel dimensions and material rear 10 J x 18 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions.





BMW Z4 Roadster M40i[1]:
Fuel consumption in l/100 km (combined): 8.0–7.8
CO2 emissions in g/km (combined): 181–175


[1]Values are preliminary


Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195.


For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp


Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the "Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.





Read more
​

Fuel consumption and CO2 emissions.

  • BMW Z4 Roadster M40i(1):
    Fuel consumption in l/100 km (combined): 8.0–7.8
    CO2 emissions in g/km (combined): 182–177

    (1)Values are preliminary

    Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195.

    For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

    Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the "Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.
