TECHNICAL DATA OF THE BMW X3.

Weight
Unladen weight EU in kg
1,735
Max. permissible weight in kg
2,330
Permitted load in kg
660
Permitted axle load front/rear in kg
1,070/1,370
Luggage capacity min. (seats up or roof down) in l
550
Luggage capacity max. (seats down or roof up) in l
1,600
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,597
Stroke/bore in mm
75.6/82.0
Engine power in kW (PS) at 1/min
125 (170)/5,000-6,000
Engine torque (Nm) at 1/min
250/1,500-4,700
Compression ratio : 1
9.0
Performance
Top speed in km/h
208
Acceleration 0–100 km/h in s
9.1
Fuel consumption
Urban in l/100 km
8.4-7.9
Extra-urban in l/100 km
6.9-6.7
Combined in l/100 km
7.4-7.1
CO2 combined emissions in g/km
169-163
Tank capacity, approx. in l
65
Wheels
Tyre dimensions front
225/60 R18 104W XL
Tyre dimensions rear
225/60 R18 104W XL
Wheel dimensions and material front
7 J x 18 inches, light-alloy
Wheel dimensions and material rear
7 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,790
Max. permissible weight in kg
2,400
Permitted load in kg
660
Permitted axle load front/rear in kg
1,140/1,370
Luggage capacity min. (seats up or roof down) in l
550
Luggage capacity max. (seats down or roof up) in l
1,600
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (PS) at 1/min
135 (184)/5,000-6,500
Engine torque (Nm) at 1/min
290/1,350-4,250
Compression ratio : 1
11.0
Performance
Top speed in km/h
215
Acceleration 0–100 km/h in s
8.3
Fuel consumption
Urban in l/100 km
8.8-8.5
Extra-urban in l/100 km
6.5-6.3
Combined in l/100 km
7.1-7.3
CO2 combined emissions in g/km
168-163
Tank capacity, approx. in l
65
Wheels
Tyre dimensions front
225/60 R18 104W XL
Tyre dimensions rear
225/60 R18 104W XL
Wheel dimensions and material front
7 J x 18 inches, light-alloy
Wheel dimensions and material rear
7 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,790
Max. permissible weight in kg
2,400
Permitted load in kg
660
Permitted axle load front/rear in kg
1,140/1,370
Luggage capacity min. (seats up or roof down) in l
550
Luggage capacity max. (seats down or roof up) in l
1,600
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (PS) at 1/min
185 (252)/5,200-6,500
Engine torque (Nm) at 1/min
350/1,450-4,800
Compression ratio : 1
10.2
Performance
Top speed in km/h
240
Acceleration 0–100 km/h in s
6.3
Fuel consumption
Urban in l/100 km
8.5-8.4
Extra-urban in l/100 km
6.7-6.4
Combined in l/100 km
7.3-7.2
CO2 combined emissions in g/km
168-164
Tank capacity, approx. in l
65
Wheels
Tyre dimensions front
225/60 R18 104W XL
Tyre dimensions rear
225/60 R18 104W XL
Wheel dimensions and material front
7 J x 18 inches, light-alloy
Wheel dimensions and material rear
7 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,885
Max. permissible weight in kg
2,455
Permitted load in kg
640
Permitted axle load front/rear in kg
1,190/1,375
Luggage capacity min. (seats up or roof down) in l
550
Luggage capacity max. (seats down or roof up) in l
1,600
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (PS) at 1/min
260 (354)/5,500-6,500
Engine torque (Nm) at 1/min
500/1,550-4,500
Compression ratio : 1
11.0
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.8
Fuel consumption
Urban in l/100 km
11.3-11.5
Extra-urban in l/100 km
7.8-7.9
Combined in l/100 km
9.1-9.1
CO2 combined emissions in g/km
207-206
Tank capacity, approx. in l
65
Wheels
Tyre dimensions front
245/45 R20 103W XL
Tyre dimensions rear
275/40 R20 106W XL
Wheel dimensions and material front
8 J x 20 inches, light-alloy
Wheel dimensions and material rear
9.5 J x 20 inches, light-alloy
Weight
Unladen weight EU in kg
1,725 [1,735]
Max. permissible weight in kg
2,355 [2,355]
Permitted load in kg
660 [660]
Permitted axle load front/rear in kg
1,070/1,370 [1,070/1,390]
Luggage capacity min. (seats up or roof down) in l
550 [550]
Luggage capacity max. (seats down or roof up) in l
1,600 [1,600]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
2,000 [2,000]
Trailer load 12% (braked) in kg
2,000 [2,000]
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
110 (150)/4,000
Engine torque (Nm) at 1/min
350/1,500-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
200 [198]
Acceleration 0–100 km/h in s
9.5 [9.7]
Fuel consumption
Urban in l/100 km
5.7-5.3
Extra-urban in l/100 km
5.1-4.8
Combined in l/100 km
5.3-5.0
CO2 combined emissions in g/km
131-139
Tank capacity, approx. in l
58
Wheels
Tyre dimensions front
225/60 R18 104W XL
Tyre dimensions rear
225/60 R18 104W XL
Wheel dimensions and material front
7 J x 18 inches, light-alloy
Wheel dimensions and material rear
7 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,825
Max. permissible weight in kg
2,420
Permitted load in kg
660
Permitted axle load front/rear in kg
1,135/1,395
Luggage capacity min. (seats up or roof down) in l
550
Luggage capacity max. (seats down or roof up) in l
1,600
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
213
Acceleration 0–100 km/h in s
8.0
Fuel consumption
Urban in l/100 km
5.9-5.6
Extra-urban in l/100 km
5.3-5.1
Combined in l/100 km
5.5-5.3
CO2 combined emissions in g/km
145-139
Tank capacity, approx. in l
60
Wheels
Tyre dimensions front
225/60 R18 104W XL
Tyre dimensions rear
225/60 R18 104W XL
Wheel dimensions and material front
7 J x 18 inches, light-alloy
Wheel dimensions and material rear
7 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,840
Max. permissible weight in kg
2,435
Permitted load in kg
660
Permitted axle load front/rear in kg
1,145/1,400
Luggage capacity min. (seats up or roof down) in l
550
Luggage capacity max. (seats down or roof up) in l
1,600
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
170 (231)/4,400
Engine torque (Nm) at 1/min
500/2,000
Compression ratio : 1
16.5
Performance
Top speed in km/h
230
Acceleration 0–100 km/h in s
6.8
Fuel consumption
Urban in l/100 km
6.3-6.2
Extra-urban in l/100 km
5.3-5.1
Combined in l/100 km
5.7-5.5
CO2 combined emissions in g/km
150-145
Tank capacity, approx. in l
60
Wheels
Tyre dimensions front
225/60 R18 104W XL
Tyre dimensions rear
225/60 R18 104W XL
Wheel dimensions and material front
7 J x 18 inches, light-alloy
Wheel dimensions and material rear
7 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,895
Max. permissible weight in kg
2,500
Permitted load in kg
660
Permitted axle load front/rear in kg
1,190/1,415
Luggage capacity min. (seats up or roof down) in l
550
Luggage capacity max. (seats down or roof up) in l
1,600
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
195 (265)/4,000
Engine torque (Nm) at 1/min
620/2,000-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
240
Acceleration 0–100 km/h in s
5.8
Fuel consumption
Urban in l/100 km
6.9-6.7
Extra-urban in l/100 km
5.6-5.4
Combined in l/100 km
6.0-5.9
CO2 combined emissions in g/km
159-154
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/60 R18 104W XL
Tyre dimensions rear
225/60 R18 104W XL
Wheel dimensions and material front
7 J x 18 inches, light-alloy
Wheel dimensions and material rear
7 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,970
Max. permissible weight in kg
2,550
Permitted load in kg
640
Permitted axle load front/rear in kg
1,220/1,425
Luggage capacity min. (seats up or roof down) in l
550
Luggage capacity max. (seats down or roof up) in l
1,600
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
240 (326)/4,400
Engine torque (Nm) at 1/min
680/1,750-2,750
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.9
Fuel consumption
Urban in l/100 km
7.4-7.2
Extra-urban in l/100 km
6.1-5.8
Combined in l/100 km
6.5-6.4
CO2 combined emissions in g/km
172-169
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
245/45 R20 103W XL
Tyre dimensions rear
275/40 R20 106W XL
Wheel dimensions and material front
8 J x 20 inches, light-alloy
Wheel dimensions and material rear
9.5 J x 20 inches, light-alloy

Fuel consumption and CO2 emissions of the BMW X3.

  • BMW X3 M40i:
    Fuel consumption in l/100 km (combined): 9.1
    CO2 emissions in g/km (combined): 207–206

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
