BMW M3 Sedan G80 2020 Isle of Man Green metallic side view worm's-eye view

THE M3

BMW M

THE NEW BMW 3 SERIES SEDAN M AUTOMOBILES: ENGINES & TECHNICAL DATA.

THE M3THE NEW BMW 3 SERIES SEDAN M AUTOMOBILES: ENGINES & TECHNICAL DATA.
BMW 3 Series Sedan M Automobiles: Overview

Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW M3 Competition Sedan.

Read more

BMW 3 SERIES SEDAN M AUTOMOBILES: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1,730
Max. permissible weight in kg 2,210
Permitted load in kg 480
Permitted axle load front/rear in kg 1,080/1,180
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 375 (510)/6,250
Engine torque (Nm) at 1/min 650/2,750-5,500
Compression ratio : 1 9.3

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 3.9

Fuel consumption

Combined in l/100 km 9.8
CO2 combined emissions in g/km 224-223
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 275/40 ZR18 (103Y) XL
Tyre dimensions rear 285/35 ZR19 (103Y) XL
Wheel dimensions and material front 9.5Jx18 inches, light-alloy
Wheel dimensions and material rear 10.5Jx19 inches, light-alloy

Weight

Unladen weight EU in kg 1.855
Max. permissible weight in kg 2,260
Permitted load in kg 480
Permitted axle load front/rear in kg 1,125/1,200
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 375 (510)/6,250
Engine torque (Nm) at 1/min 650/2,750-5,500
Compression ratio : 1 9.3

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 3.5

Fuel consumption

Combined in l/100 km 10.1-10.0
CO2 combined emissions in g/km 230-228
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 275/35 ZR19 (100Y) XL
Tyre dimensions rear 285/30 ZR20 (99Y) XL
Wheel dimensions and material front 9.5 J x 19 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 20 inches, light-alloy

Weight

Unladen weight EU in kg 1,780
Max. permissible weight in kg 2,210
Permitted load in kg 505
Permitted axle load front/rear in kg 1,080/1,180
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 353 (480)/6,250
Engine torque (Nm) at 1/min 550/2,650-6,130
Compression ratio : 1 9.3

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.2

Fuel consumption

Combined in l/100 km 10.2-10.0
CO2 combined emissions in g/km 231-227
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 275/40 ZR18 (103Y) XL
Tyre dimensions rear 285/35 ZR19 (103Y) XL
Wheel dimensions and material front 9.5Jx18 inches, light-alloy
Wheel dimensions and material rear 10.5Jx19 inches, light-alloy

Weight

Unladen weight EU in kg 1.875
Max. permissible weight in kg 2,340
Permitted load in kg 540
Permitted axle load front/rear in kg 1,155/1,260
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 250 (340)/4,400
Engine torque (Nm) at 1/min 700/1,750-2,250
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.6

Fuel consumption

Combined in l/100 km 6.4-5.9
CO2 combined emissions in g/km 169-154
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions.

BMW M3 Competition Sedan with M xDrive:
Fuel consumption in l/100 km (combined): 10.1–10.0
CO2 emissions in g/km (combined): 230–228

BMW M3 Competition Sedan:
Fuel consumption in l/100 km (combined): 9.8
CO2 emissions in g/km (combined): 224–223

BMW M3 Sedan:
Fuel consumption in l/100 km (combined): 10.2–10.0
CO2 emissions in g/km (combined): 231–227

BMW M340i xDrive Sedan:
Fuel consumption in l/100 km (combined): x.x–x.x
CO2 emissions in g/km (combined): xxx–xxx

BMW M340i Sedan:
Fuel consumption in l/100 km (combined): x.x–x.x
CO2 emissions in g/km (combined): xxx–xxx

BMW M340d xDrive Sedan:
Fuel consumption in l/100 km (combined): x.x–x.x
CO2 emissions in g/km (combined): xxx–xxx

Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more
​

Fuel consumption and CO2 emissions.

  • BMW M3 Competition Sedan with M xDrive:
    Fuel consumption in l/100 km (combined): 10.1–10.0
    CO2 emissions in g/km (combined): 230–228

    BMW M3 Competition Sedan:
    Fuel consumption in l/100 km (combined): 9.8
    CO2 emissions in g/km (combined): 224–223

    BMW M3 Sedan:
    Fuel consumption in l/100 km (combined): 10.2–10.0
    CO2 emissions in g/km (combined): 231–227

    BMW M340i xDrive Sedan:
    Fuel consumption in l/100 km (combined)*: 8.5–7.8
    CO2 emissions in g/km (combined)*: 192–177

    BMW M340d xDrive Sedan:
    Fuel consumption in l/100 km (combined): 6.4–5.9
    CO2 emissions in g/km (combined): 169–154

    * Provisional figures

    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
