BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

THE 3BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

TECHNICAL DATA.

Weight
Unladen weight EU in kg
1,645
Max. permissible weight in kg
2.135
Permitted load in kg
565
Permitted axle load front/rear in kg
975/1,260
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115 (156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
220
Acceleration 0–100 km/h in s
8.7
Fuel consumption
Combined in l/100 km
6.6
CO2 combined emissions in g/km
151
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,645
Max. permissible weight in kg
2.135
Permitted load in kg
565
Permitted axle load front/rear in kg
975/1,260
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,600
Trailer load 12% (braked) in kg
1,600
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
135 (184)/5,000-6,500
Engine torque (Nm) at 1/min
300/1,350-4,000
Compression ratio : 1
11.0
Performance
Top speed in km/h
230
Acceleration 0–100 km/h in s
7.5
Fuel consumption
Combined in l/100 km
6.6
CO2 combined emissions in g/km
151
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,670
Max. permissible weight in kg
2.185
Permitted load in kg
590
Permitted axle load front/rear in kg
985/1,280
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,600
Trailer load 12% (braked) in kg
1,600
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
190 (258)/5,000-6,500
Engine torque (Nm) at 1/min
400/1,550-4,400
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.9
Fuel consumption
Combined in l/100 km
6.9
CO2 combined emissions in g/km
156
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,730
Max. permissible weight in kg
2,260
Permitted load in kg
605
Permitted axle load front/rear in kg
1,050/1,295
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
190 (258)/5,000-6,500
Engine torque (Nm) at 1/min
400/1,550-4,400
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.8
Fuel consumption
Combined in l/100 km
7.2
CO2 combined emissions in g/km
165
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,650 [1,660]
Max. permissible weight in kg
2,160 [2,180]
Permitted load in kg
585 [595]
Permitted axle load front/rear in kg
980/1,270 [985/1,280]
Luggage capacity min. (seats up or roof down) in l
500 [500]
Luggage capacity max. (seats down or roof up) in l
1,510 [1,510]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
1,600 [1,800]
Trailer load 12% (braked) in kg
1,600 [1,800]
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
110 (150)/4,000
Engine torque (Nm) at 1/min
320/1,500-3,000
Compression ratio : 1
16.5
Performance
Top speed in km/h
217 [215]
Acceleration 0–100 km/h in s
8.9 [8.8]
Fuel consumption
Combined in l/100 km
5.1
CO2 combined emissions in g/km
134
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,655 [1,675]
Max. permissible weight in kg
2,180 [2,190]
Permitted load in kg
600 [590]
Permitted axle load front/rear in kg
985/1,280 [995/1,285]
Luggage capacity min. (seats up or roof down) in l
500 [500]
Luggage capacity max. (seats down or roof up) in l
1,510 [1,510]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
1,600 [1,800]
Trailer load 12% (braked) in kg
1,600 [1,800]
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
229 [230]
Acceleration 0–100 km/h in s
7.5 [7.1]
Fuel consumption
Combined in l/100 km
4.9-5.1
CO2 combined emissions in g/km
128-133
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,735
Max. permissible weight in kg
2,255
Permitted load in kg
595
Permitted axle load front/rear in kg
1,055/1,300
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
225
Acceleration 0–100 km/h in s
7.4
Fuel consumption
Combined in l/100 km
5.1
CO2 combined emissions in g/km
134
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7,5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7,5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,790
Max. permissible weight in kg
2,305
Permitted load in kg
590
Permitted axle load front/rear in kg
1,075/1.325
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
195 (265)/4,000
Engine torque (Nm) at 1/min
580/1,750-2,750
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.6
Fuel consumption
Combined in l/100 km
6.0
CO2 combined emissions in g/km
158
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,835
Max. permissible weight in kg
2,350
Permitted load in kg
590
Permitted axle load front/rear in kg
1,105/1,340
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
195 (265)/4,000
Engine torque (Nm) at 1/min
580/1,750-2,750
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.4
Fuel consumption
Combined in l/100 km
6.3
CO2 combined emissions in g/km
166
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,845
Max. permissible weight in kg
2.365
Permitted load in kg
595
Permitted axle load front/rear in kg
935/1,095
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
275 (374)/5,500-6,500
Engine torque (Nm) at 1/min
500/1,850-5,500
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.5
Fuel consumption
Combined in l/100 km
8.2
CO2 combined emissions in g/km
187
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/45 R18 95 Y XL
Tyre dimensions rear
255/40 R18 99 Y XL
Wheel dimensions and material front
7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear
8.5 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,955
Max. permissible weight in kg
2,415
Permitted load in kg
535
Permitted axle load front/rear in kg
1,155/1,360
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
250 (340)/4,400
Engine torque (Nm) at 1/min
700/1,750-2,250
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.6
Fuel consumption
Combined in l/100 km
6.5
CO2 combined emissions in g/km
169
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/45 R18 95Y XL
Tyre dimensions rear
255/40 R18 99Y XL
Wheel dimensions and material front
7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear
8.5 J x 18 inches, light-alloy
